Massivit 1800 Pro 3D Printer

Available on backorder
Ultra-fast solution for large-scale production
  • Enhanced performance
  • New printing modes
  • Advanced slicing and monitoring
  • Remote control
We Accept Purchase Orders From All Educational Institutions and Eligible Business Customers
This 3D printer comes with:
  • All necessary tools
  • 9.6" tablet
  • User manual
  • Power cable
Order now and we’ll ship it in 24 hours or less

The Massivit 1800 Pro is an industrial-grade 3D printer for truly massive manufacture. With the unique Gel Dispensing Printing (GDP) method, the machine produces super-size quality prints at an unprecedented speed — up to 30X the speed of other technologies. Compared to the original model, the Pro version has a wider range of print modes, such as Variable Resolution and Mega Quality — that will be of great use for the signage market, not to mention its immense industrial application capacity. The smart features and enormous build volume of the Massivit 1800 Pro will serve you in the most cost-effective way.

Thanks to the two independent print heads, the Massivit 1800 Pro boasts brilliant workflow flexibility with almost no manual labor. You can control the entire process remotely while getting flawless results due to the advanced automated functions.

a black sportcar

Credit: @massivit3d / Instagram

The user-friendly interface and multiple handy functions allow creating large, complex objects in ultra-fast and highly detailed manner.

a green model dragon printed on the Massivit 1800 Pro 3D printer

Credit: @tfp_grafika / Instagram

Look through the following table to compare the specs of the Massivit 1800 Pro with those of the original model and the next iteration, Massivit 5000.



Massivit 1800

Massivit 1800 Pro

Massivit 5000

No. of printing heads

1 (not upgradable)

1 or 2, with option to upgrade

2 printing heads

Print speed

300 mm/sec linear speed. 35 cm / 13.7" on Z axis per hour. (Printing speed for 1-meter diameter cylinder)

Layer thickness

  • Normal (1.3mm)

  • Quality (1mm)

  • High Resolution (0.8mm)

  • Normal (1.3mm)

  • Quality (1mm)

  • High Resolution (0.8mm)

  • Fast (1.5mm)

  • Normal (1.3mm)

  • Quality (1mm)

  • High Resolution (0.8mm)

  • High Definition (0.5mm)

Special printing modes



Mega-Quality — rapid, high quality printing of large objects allowing gel cost efficiency



Variable Resolution — predefine multiple resolutions per model according to required strength and quality

Mega-Quality — rapid, high quality printing of large objects allowing gel cost efficiency



Variable Resolution — predefine multiple resolutions per model according to required strength and quality



Mold Mode — produce architectural elements, restorations, street furniture with concrete or plaster casting

Max. printing volume

145 cm x 111 cm x 180 cm or 57" x 44" x 70"

Supported materials

  • Dimengel 90 — all-purpose, cost-friendly

  • Dimengel 100 — all-purpose/ translucent

  • Dimengel 90 — all-purpose, cost-friendly

  • Dimengel 100 — all-purpose/ translucent

  • Dimengel 90 — all-purpose, cost-friendly

  • Dimengel 100 — all-purpose/ translucent

  • Dimengel 110 —  high definition and enhanced model fidelity

Material system

Single

Double

Cleaning mechanism

Auto cleaning (time-based)

Print head camera with image recognition provides automated, efficient cleaning as required.

Slicing

Integrated user-friendly software plus one Massivit SMART Slicer license (purchased separately). Sophisticated algorithms for easy file preparation. Includes instant EstimatorTool.

Integrated user-friendly software plus advanced Massivit SMART Pro Slicer with one complimentary license (purchased separately). Sophisticated algorithms for easy file preparation. Includes Estimator Tool plus additional features and modes such as Variable Resolution and Mega-Quality.

Integrated user-friendly software plus advanced Massivit SMART Pro Slicer with two complimentary licenses. Sophisticated algorithms for easy file preparation. Includes Estimator Tool plus additional features and modes such as Mold Mode, Variable Resolution, and Mega-Quality. Additional automation features to increase workflow efficiency.

Advanced monitoring

Camera on printing head tip for monitoring.

Camera on printing head tip for monitoring.

Camera on printing head tip for monitoring. Additional 40" flat panel screen displays live output from three internal cameras (recording capability for marketing purposes included).

Remote control

Remote monitoring, operations and support available via a range of computers, tablets, and phones.

Complimentary 9.6” tablet provided for convenient remote monitoring, operations, and support.

Remote monitoring, operations and support available via a range of computers, tablets, and phones.



Print quality

The Massivit 1800 Pro uses a unique technology that allows it to print layers from 1.3 to 0.8 mm providing opportunities for high resolution mass printing. Unlike its predecessor, the machine introduces new print modes. With Mega-Quality, you choose fast and precise printing of large objects.

The immense level of detail makes this Triceratops terrifyingly realistic.

a grey model head dinosaur printed on the Massivit 1800 Pro 3D printer

Credit: @imprefincorp / Instagram

The Variable Resolution mode enables you to set multiple resolutions for a single model while preserving excellent quality and strength of the outprint.



Materials

As consumables, the Massivit 1800 Pro uses the proprietary Dimengel photopolymer acrylic gel combining outstanding properties with rapid curing.

a different colour materials used on the Massivit 1800 Pro 3D printer

Credit: @CameronAdvertising / Facebook



Build volume

a white model head donkey printed on the Massivit 1800 Pro 3D printer

Credit: @dwl_studios / Instagram

The build area of 57 x 44 x 70 inches (145 cm x 111 cm x 180 cm) lets you print huge, life-sized models in one go. Thanks to its massiveness, it is possible to produce multiple large items as well.

The image above shows a donkey head model 2.5 ft tall.



Printer controls

The Massivit 1800 Pro is equipped with an ultra-large HD touchscreen for comfortable control, with its intuitive interface allowing users to easily manage the printing process.

a printer touchscreen controls on the Massivit 1800 Pro 3D printer

It is also possible to control the machine remotely via smartphone or tablet. The camera on the print head tip allows for remote monitoring.

a control tablet on the Massivit 1800 Pro 3D printer

3D models can be printed from a computer via the local area network.

a Massivit SMART Pro Slicer software on the Massivit 1800 Pro 3D printer

The printer comes with the integrated software and one complementary Massivit SMART Pro Slicer license (an additional license can be purchased separately). The software works with 3D models in the common STL file format. Its intuitive UI and automated functions will greatly facilitate the production. You can scale, rotate, and slice 3D files according to one of the chosen print modes as well as adjust print quality and speed. The program includes additional features and modes such as Variable Resolution and Mega-Quality. It also comes with the instant Estimator Tool. The Massivit SMART Pro Slicer is available for Windows.



Look and feel

Massivit 1800 Pro 3D printer

The Massivit 1800 Pro is available in a white and gray color scheme. Its astonishing look makes it ideal for truly high endeavors in a number of applications.

The printer dimensions are 10.2 x 7.3 x 9.2 ft (3.1 x 2.2 x 2.8 m). It weighs 5511 lb (2500 kg).



Price

To learn the current price of the Massivit 1800 Pro, click the "request the quote" button and fill in the form. We will contact you as soon as possible and send you all the details.
