OnRobot Screwdriver Tool

In Stock
Multifunctional robotic screwdriving module with screw feeder
  • Precise force control
  • Smart error detection
  • Wide range of compatible screws
  • Out-of-the-box deployment
When purchasing with us you get:
  • FREE training
  • 1 Year Warranty
  • 24/5 Customer Support
  • Delivery: FREE
We Accept Purchase Orders From All Educational Institutions and Eligible Business Customers
This module comes with:
  • Screw Feeder M1.6 or M2–M6
  • Magnetic Bit holders
  • Screw Bits and carriers
  • Wrench tool
The estimated lead time is 5-10 business days.

The OnRobot Screwdriver is an automated screwdriving tool for the majority of light industrial and collaborative robots. It features fast deployment, simplified installation, programming, and maintenance with no custom engineering required. The Screwdriver comes as a complete solution with everything you need to start it right out of the box. The module provides flexible settings and intelligent error detection as well as multiple screw size and length handling, which ensures consistent high-quality results and significantly reduces your production cycle time.

The main peculiarity of the Screwdriver is its smart functionality, including enhanced torque control, additional safety mechanisms, and more. The device can be easily managed through an intuitive software interface providing quick set up and minimized programming. Due to these user-friendly peculiarities, the Screwdriver is ideal for beginners with little technical expertise as well as experienced users.

OnRobot Screwdriver Tool

The OnRobot Screwdriver Tool is a simple and affordable solution for advanced collaborative application. The device is great for intelligent assembly operations requiring automated and safe screwdriving.



Key features

The OnRobot Screwdriver is a versatile robotic solution with a number of impressive features making for fast and simple automation.

a key features on the OnRobot Screwdriver Tool



Great serviceability

The OnRobot Screwdriver boasts fast deployment, simplified controls, quick programming, high performance, and favorable price, which makes it a completely user-friendly and cost-effective solution for a variety of applications.



Integrated protection

Thanks to the advanced safety algorithms, screws up to 30 mm long will be withdrawn inside the module during its movement. The device also offers the Safety Stop function that activates automatically if a screw is exposed to excessive force.



Precise moves

Since screws are retracted inside the tool and driven automatically once the robot arm moves into the required position, the Screwdriver greatly facilitates programming and reduces the robot’s movement.



Self-tapping functionality

The usage of the module enables applications for screwing while tapping the thread into pre-drilled holes.



Compatible with a wide array of screws

The OnRobot Screwdriver handles multiple screw sizes from M1.6 to M6 up to 50 mm long. It can switch between different screw types or sizes in just a few minutes, which results in reduced downtime and increased ROI.



Even more applications

Due to additional Bit Extenders (50 mm and 100 mm), the tool gets extra reach capabilities allowing it to work in narrow and tight spaces.



Adjustable torque range

You can control torque within 0.15–5 Nm range to ensure consistent and accurate screwdriving for any task.



ESD certified tool

The module is officially certified for work in all assembly environments, including electronics.



Applications

The OnRobot Screwdriver boasts a flexible and adaptable structure that can be easily customized according to the assigned operations. The module empowers the robots with new extended capabilities for effective assembly processes across multiple industries, which is highlighted in the following video by the example of the robots:

As can be seen, this efficient screwdriving tool is perfect for safe collaborative applications. With a number of handy automated features, it allows you to get greater consistency, high-output results, and increased protection without safety equipment or barriers.

OnRobot Screwdriver Tool

Thanks to the implementation of this handy module, your human employees can focus on more important assignments by automating repetitive tasks.



Connectivity and control

The OnRobot Screwdriver Tool can be easily programmed through the Compute Box control unit that performs the processing functions. It can read and configure the device via an intuitive Ethernet interface.

a connectivity and control on the OnRobot Screwdriver Tool

Due to its simplified control that does not require additional training, only basic robot knowledge, the Screwdriver can be effectively applied by both seasoned and inexperienced users. Moreover, the universally compatible design will make integration with a full range of robotic platforms as fast and easy as possible.



What’s in the box

OnRobot Screwdriver Tool kit

  • OnRobot Screwdriver Tool
  • Screw Feeder M1.6 or Screw Feeder M2–M6
  • Wrench tool
  • Magnetic Bit holder A
  • Magnetic Bit holder B
  • Screw Bits (Imperial or Metric)
  • Screw carriers (Imperial or Metric)
  • User manual

For some items, package content may change. In case of any questions, please get in touch.



Look and feel

OnRobot Screwdriver Tool

The OnRobot Screwdriver comes in stainless steel with black and blue trimmings. Its stylish look makes it ideal for advanced industry applications and will decorate any factory, workshop, or lab.

The outer dimensions of the tool are 12.1 x 3.4 x 4.5 in (308 x 86 x 114 mm). It weighs 5.51 lb (2.5 kg).



Price

To learn the current price of the OnRobot Screwdriver Tool, click the "request the quote" button and fill in the form. We will contact you as soon as possible and send you all the details.
