The HBD 1000 is an industrial SLM (Selective Laser Melting) machine capable of producing high-quality prototypes and functional parts in a variety of materials. It comes as a comprehensive, fully customizable solution with a number of auxiliaries that meets most demanding metal 3D printing needs while still being an affordable entry point for SLM technology.
The HBD 1000 is available in two versions — with four 500W or 1000W lasers. Both configurations feature a huge build chamber that is perfectly combined with their outstanding sintering capacity. Thanks to the scanning speed of 10000 mm/s, the build process is characterized by elevated productivity. The flexible multi-purpose software with a set of user-friendly functions allows for smooth operation. To make it even better, you can opt for additional equipment available for optional order.
Apart from the mentioned benefits, the HBD 1000 boasts a number of advanced features making for a simplified, effective, and completely safe working process. The list includes closed automated powder circulation system, independent long-term multi-stage purification, highly integrated post-processing unit, real-time status light indicators, sealed glove structure, door open detection system, autonomous monitoring of oxygen content, and easy access to the printing area contributing to a safe environment.
Due to its advanced capabilities, uninterrupted operation, and satisfying forming size, the HBD 1000 SLM system is ideal for professional use in many demanding industries requiring high accuracy, good mechanical qualities, and intelligent 24/7 operation under high intensity conditions. The machine is suitable for aerospace and automotive purposes as well as medical, energy, engineering, and other spheres.
The HBD 1000 can sinter layers with a minimum thickness of 30 microns that can be further adjusted to the user’s needs. The printer is equipped with four potent 500W or 1000W lasers and a powerful SCANLAB galvo system with a minimum scanning track width of 70 microns to ensure high accuracy up to 0.05 mm and rich detail of printed items.
With the HBD 1000, you can create unique models of complex geometries unachievable with traditional materials and simplify the manufacturing process by directly printing your final design in precious metals instead of producing wax castings.
The HBD 1000 3D printer works with a wide selection of metal powders with different properties that suit various applications. The machine is fully compatible with stainless steel, cobalt-chrome alloy, tool steel, titanium alloy, nickel-based alloy, high-temperature alloy, aluminum alloy, hastelloy, and some refractory metals like Tungsten and Tantalum. This open system lets the printer build both prototypes and end-use parts without any issues.
The HBD 1000 SLM 3D printer is engineered with an impressively large forming space of 23.6 x 23.6 x 39.4 inches (600 x 600 x 1000 mm). It lets you print the majority of items as a whole, without splitting them into several parts, or small to medium objects in batches. This makes for sufficient production speed and effective material usage.
The HBD 1000 can be operated via a built-in control unit with a clear and user-friendly interface.
The SLM system is supplied with the independently developed multifunctional HBD Build Expert slicing software. The program provides a variety of smart tools for data slicing, path planning, intelligent measurement, material development, printing parameter editing, multi-laser coordinating, and other handy functions.
The HBD 1000 supports the use of Materialise Magics allowing for advanced data and build preparation. Due to this software solution, you can program builds efficiently by using such innovative features as part orientation, support creation, part nesting checks, smart slicing algorithms, and more.
To tailor the machine to your specific production needs, you can also order optional items from the list below:
For some items, package content may change. In case of any questions, please get in touch.
The HBD 1000 model is available in white with black trimmings. Its stylish look makes it ideal for a range of professional applications within multiple industries, including aerospace, automotive, aviation, medical, jewelry, prototyping, scientific research, energy, education, and more.
To learn the current price of the HBD 1000 3D printer, click the "request the quote" button and fill in the form. We will contact you as soon as possible and send you all the details.
