Intamsys PEI 1010 1.75 mm 500 g / 1 kg

In Stock

Ultra-high-performance amorphous thermoplastic

Superior thermal resistance up to 217 °C
Exceptional mechanical strength
Inherent flame retardancy
Chemical resistance to automotive fluids and solvents

Highlights

Exceptional hydrolytic stability
Low smoke emission in case of fire
Superior electrical insulation properties
Suitable for demanding industrial applications

Filament Specs

Diameter: 1.75mm
Spool weight: 500g / 1kg
Color name: Natural
Color attribute: Solid

Price $119.00

The estimated lead time is 5-10 business days.

The Intamsys PEI 1010 utilizes SABIC’s ULTEM™ 1010 resin to deliver ultra-high-performance 3D printing capabilities. This amorphous polyetherimide achieves a glass transition temperature of 217 °C and maintains mechanical properties at continuous use temperatures up to 170 °C. The material demonstrates tensile strength of 90 MPa and flexural modulus of 3427 MPa, according to standardized testing.

PEI 1010 exhibits thermal deformation temperature reaching 200 °C, which is higher than . The material achieves UL94 V-0 flame retardancy rating at 1.5mm thickness with low smoke emission characteristics. Chemical resistance properties include resistance to automotive fluids, fully halogenated hydrocarbons, alcohols, and aqueous solutions. In addition, the material withstands multiple sterilization methods including steam autoclave at 134 °C for over 1000 cycles, vaporized hydrogen peroxide gas plasma for over 300 cycles, gamma radiation, electron beam, X-ray, ethylene oxide, and UV-C sterilization. These sterilization capabilities make PEI 1010 suitable for medical device applications requiring repeated sterilization cycles.

The Intamsys PEI 1010 serves aerospace applications including aircraft interior components and structural elements requiring flame retardancy compliance. Medical applications encompass surgical instruments, housings for medical equipment, and sterilizable components. Automotive applications include under-the-hood components, housings, and ducts requiring high-temperature resistance. Electronics applications feature electrical enclosures and insulating components requiring dimensional stability and chemical resistance.

The Intamsys PEI 1010 1.75 mm filament is sold in 500 g / 1 kg spools. It comes vacuum-sealed with desiccant.

Drying temperature	130–150 °C for 6–8 hours
Filament diameter	1.75 mm
Available colors	Natural
Chamber temperature	85–90 °C
Color attribute	Solid
Continuous use temperature	Up to 170 °C
Density	1.27 g/cm³
Elongation at break	3–3.3%
Filament weight	500 g / 1 kg
Flexural modulus	2510–3200 MPa
Flexural strength	110–160 MPa
Glass transition temperature	217 °C
Heat deflection temperature	207–208 °C at 0.45 MPa
Impact strength	0.3–5.0 kJ/m²
Nozzle temperature	350–400 °C
Print bed temperature	120–160 °C
Sterilization compatibility	Steam autoclave, VHP, gamma, EtO, UV-C
Suitable 3D printers	High-temperature enclosed systems with all-metal hotend
Support material	Peel-type supports recommended
Tensile modulus	2500–3427 MPa
Tensile strength	56–90 MPa
Thermal deformation	200 °C
UL94 flame rating	V-0 at 1.5mm and 3mm thickness
