The AXIOM 20 is a large-format FDM professional 3D printer. It is a robust, fully enclosed printer made with durable, high-grade aluminum parts, which make it durable yet lightweight. It is available as a dual- or single extruder printer and supports interchangeable nozzles. The Dual Direct Drive version features two independent nozzles, which allow for multi-material and multi-color printing. It can produce full-density parts running for more than 200 hours uninterruptedly. It adopts a double-sided, heated bed made of flex-resistant, borosilicate glass. The automatic bed leveling avoids time-consuming manual calibration. It includes wireless connectivity over Wi-Fi and a user-friendly LCD screen for seamless user experience. The machine is able to print with a wide range of filaments, including difficult-to-print ones. It’s successfully used for prototyping and small-scale manufacturing in a variety of industries. For example, it has been used to produce cosplay costumes, functional tools, automotive parts, and more. Keep reading to learn more about the Axiom 20.
The printer has been used to 3D print an ABS-made transfer case. Despite its large size, it looks really good and accurate.
Credit: @airwolf3d / instagram
The picture shows the before and after cleaning versions of a big control arm for an ATV. Notice how smooth and well-defined it is.
Credit: @airwolf3d / instagram
The AXIOM 20 Large Format 3D Printer is an FDM 3D printer that can print layers at 40 microns. This way you can produce parts with smooth exterior surfaces. The full enclosure creates a thermally stable environment for top-notch print quality and no warping issues.
Look how polished and precise this real-scale, 3D printed pulley is.
Credit: @oasd / instagram
The AXIOM 20 Large Format 3D Printer comes standard with a 0.5 mm nozzle. The printer supports additional, easy-to-swap nozzles (from 0.8 to 0.35mm). You can use the 0.35 nozzle to achieve finer details or the 0.8 one to benefit from truly strong models and fast print times.
The print head runs on rods with linear bearings, making the design more simple, lightweight and effective, all characteristics that are desirable in a 3D printer. In addition, the printer adopts a Z-axis supported by a precision ball screw, which guarantees high repeatability and zero recoils.
AXIOM 20 Large Format 3D Printer prints with over 40 thermoplastic materials, including ABS, PC, PP, Nylons, TPE, TPU, and other materials.
The extruder comes with fans for printing with PLA-type materials. By cooling the model down, it reduces warping, stringing and, generally, makes for higher quality prints.
Unlike many FDM printers, the EVO 22 Large 3D Printer has a heated print bed that heats up to 150°C and a closed print chamber, which means it can reliably print with ABS-type materials.
The extruder has a maximum working temperature of 599 °F (315 °C), which means it can print high-temperature materials like PEEK, ABS/PC, PEI, carbon fiber and glass fiber.
The AXIOM 20 Large Format 3D Printer prints with 2.85 mm filament, providing you with a wide choice of materials.
The build area of 12.5 x 12 x 20 inches (317 x 304 x 508 mm) lets you print just about anything, even an imposing spiral tower.
Made of ABS filament and Wolfbite bed adhesion solution, it turned out pretty well and highly detailed.
Credit: @airwolf3d / instagram
The printer is controlled via PC or the built-in LCD interface with a rotating knob.
Credit: @airwolf3d / instagram
3D models can be printed from computer via Ethernet, Micro SD, USB Cable or over Wi-Fi.
The printer software, APEX, works with 3D models in AMF, GCODE, STL formats, and is available for macOS and Windows. Linux users will have to install a virtual machine or other software.
For some items, package content may change. In case of any questions, please get in touch.
AXIOM 20 Large Format 3D Printer is available in white with gray trimmings. Its stylish look makes it ideal for professional use, automotive industry, and educational fields alike.
The printer dimensions are 35 x 25 x 23 inches (889 x 635 x 584 mm). It weighs 80 lb (36 kg). The spool holder is mounted on the back of the printer.
The price of the AXIOM 20 Large Format 3D Printer is $9,995.00, which is reasonable considering its functionality and large build area.
